Model |
4124GO-NART
|
System Ref |
|
|
|
|
|
System FeaturesChassis Features
| Motherboard |
Dual AMD EPYC (H12DGO-6) GPU Optimised |
|
Chipset |
System-On-Chip |
| CPU Socket Type |
SP3 LGA |
|
Maximum CPU |
2 |
| RAM Slot Type |
DDR4 (Use in pairs, quads, eights, Linked to processor) |
|
Maximum RAM |
8192GB (32 x 256GB) |
| Expansion Slots |
|
8
x
SXM4 PCI-e (4.0) x16
|
2
x
M.2 Key Socket
|
|
8
x
PCI-e (4.0) x16
(LP)
|
1
x
PCI-e (4.0) x8
(LP)
|
|
1
x
AIOM LAN
(LP)
| |
|
| IO Ports |
2x USB 3.0 (Rear), 1x COM (Header), 1x VGA, LAN ports (quantity) via AIOM, 1x LAN (IPMI), 1x TPM Header |
On-board HD
controllers |
| 6 port NVMe (PCI-e 4.0)/SATA (6Gb/s)(Via PCI-e Switch & CPU ) |
|
| On-board RAID |
| 6 port NVMe (PCI-e 4.0)/SATA (6Gb/s)(RAID N/A - JBOD Mode only)(Via PCI-e Switch & CPU) |
|
|
On-board Features |
Integrated IPMI 2.0 Remote Management (AST2500 BMC) with Dedicated LAN. Supports Virtual Media over LAN and KVM over LAN. |
| On-board LAN |
| 1 x | Intel 82541PI 1 Port 100MB |
|
On-board
Graphics |
ASpeed AST2500/64(1Head)(64MB RAM) |
| General Info |
Designed for up to 8x nVidia A100 HGX GPUs (8x GPUs factory installed by default). Supports 2nd Gen. AMD EPYC 7002 Series CPUs. Featuring high speed DDR4 3200MHz RAM. Arranged as high performance eight channel mode. Also supported quad channel mode, populated in fours. |
| Name |
4U CSE-438G (A+ Server 4124GO-NART), 8x nVidia A100 HGX GPU |
| Height |
4U, 174mm |
|
Depth |
900mm |
| Width |
446mm |
|
|
|
| Bays |
| 6 x | 2.5" Hot Swap (6 bays NVMe ready) |
|
|
Front USB Ports |
2 |
| Drive Support |
6 port SATA (6Gb/s)/SAS3 (12Gb/s) /NVMe (PCI-e 3.0)/NVMe (PCI-e 4.0) |
|
Expansion Slots |
14 |
| Description |
4U A+ Server 4124GO-NART GPU solution. Supports up to 8x nVidia A100 HGX GPU adapters, with 6x Hot Swap 2.5" NVMe/SATA/SAS3. Chassis with 2200W Redundant (2+2) 80plus (Titanium) Power Supplies. |
|
|
|
Processor |
|
|
|
|
RAM |
|
|
|
| |
32GB RAM (Total), 16GB for CPU1, 16GB for CPU2
|
|
|
|
RAID on board |
|
|
|
|
RAID Controller |
|
|
|
|
RAID Controller 2 |
|
|
|
|
RAID Option |
|
|
|
|
RAID Option 2 |
|
|
|
|
H'Swap HD/SSD |
|
|
|
|
H'Swap HD/SSD2 |
|
|
|
|
H'Swap HD/SSD3 |
|
|
|
|
PCI-e SSD |
|
|
|
|
PCI-e SSD 2 |
|
|
|
|
M.2 SSD |
|
|
|
|
M.2 SSD 2 |
|
|
|
|
Graphics on board |
|
|
|
|
Graphics/GPU |
|
|
|
|
LAN on board |
|
|
|
|
LAN Installed |
|
|
|
|
LAN Controller |
|
|
|
|
LAN Controller 2 |
|
|
|
|
PSU |
|
|
|
|
Chassis Colour |
|
|
|
|
Mouse |
|
|
|
|
Monitor |
|
|
|
|
Keyboard |
|
|
|
|
Rail Kit |
|
|
|
|
Extra Peripheral |
|
|
|
|
TPM Module |
|
|
|
|
Server Manager |
|
|
|
|
Operating System |
|
|
|
|
Software |
|
|
|
|
Software 2 |
|
|
|
|
Software 3 |
|
|
|
|
Maintenance |
|
|
|
|
|
|
