Model |
R85-8324-SAS
|
System Ref |
|
|
|
|
|
System FeaturesChassis Features
| Motherboard |
Quad AMD Opteron 8000 S4985-E |
|
Chipset |
nForce Pro 2200 |
| CPU Socket Type |
Socket F (1207) |
|
Maximum CPU |
8 |
| RAM Slot Type |
DDR2 (Use in pairs, Linked to processor) |
|
Maximum RAM |
128GB (32 x 4GB) |
| Expansion Slots |
|
2
x
PCI-e x4
|
1
x
PCI 32 bit - (33 MHz)
|
|
2
x
PCI-e x16
| |
|
| IO Ports |
2 x USB 2.0 Internal, 2x USB 2.0 Rear, 1 x Serial, 1 x Parallel |
On-board HD
controllers |
| 1 port SATA (3Gb/s)(nVidia For DVD Rom) |
| 8 port SATA (3Gb/s)(nVidia MCP55 Pro ) |
|
| On-board RAID |
| 8 port SATA (3Gb/s)(RAID 0,0+1,1,5)(MCP55 Pro) For Windows use only |
|
|
On-board Features |
|
| On-board LAN |
| 2 x | Marvell 88E1111 1 Port Gigabit |
| 1 x | Intel 82541PI 1 Port Gigabit |
|
On-board
Graphics |
XGI Volari (XG20)(1Head)(16MB RAM) |
| General Info |
|
| Name |
5U C514A |
| Height |
5U, 220mm |
|
Depth |
693mm |
| Width |
430mm |
|
|
|
| Bays |
| 24 x | 3.5" Hot Swap |
| 2 x | 3.5" Internal |
| 1 x | 5.25" Slim External |
| 1 x | 3.5" Slim Floppy |
|
|
Front USB Ports |
2 |
| Drive Support |
24 port SATA (6Gb/s)/SAS2 (6Gb/s) |
|
Expansion Slots |
7 |
| Description |
Ultra high density 5U 8-way Opteron server chassis. Further support for 2x Internal 3.5" hdd or SSD bays. 1500W (3+1) Redundant Power. 24 Port SAS expander included in SAS server solutions. All 4 port SAS raid controllers will expand to 24 ports. |
|
|
|
Processor |
|
|
|
|
RAM |
|
|
|
| |
4GB RAM (Total), 4GB for CPU1
|
|
|
|
RAID on board |
|
|
|
|
RAID Controller for Internal or Rear HD/SSDs |
|
|
|
|
Internal or Rear HD/SSD |
|
|
|
|
Internal or Rear HD/SSD2 |
|
|
|
|
Internal or Rear HD/SSD3 |
|
|
|
|
RAID Controller |
|
|
|
|
RAID Controller 2 |
|
|
|
|
H'Swap HD/SSD |
|
|
|
|
H'Swap HD/SSD2 |
|
|
|
|
H'Swap HD/SSD3 |
|
|
|
|
SAS/PCI-e Card |
|
|
|
|
Graphics on board |
|
|
|
|
Graphics/GPU |
|
|
|
|
Graphics/GPU 2 |
|
|
|
|
LAN on board |
|
|
|
|
LAN Controller |
|
|
|
|
LAN Controller 2 |
|
|
|
|
IPMI |
|
|
|
|
NAS/iSCSI/SAN |
|
|
|
|
Optical Drive |
|
|
|
|
Card reader |
|
|
|
|
PSU |
|
|
|
|
Mouse |
|
|
|
|
Monitor |
|
|
|
|
Keyboard |
|
|
|
|
Rail Kit |
|
|
|
|
Extra Peripheral |
|
|
|
|
Operating System |
|
|
|
|
Software |
|
|
|
|
Software 2 |
|
|
|
|
Software 3 |
|
|
|
|
Maintenance |
|
|
|
|
|
|
