Multinode Configurator

Model F629P3-RTBN   System Ref
Multinode Enclosure
System Features Supermicro 4U quad node server solution model F629P3-RTBN, featuring four hot-pluggable system nodes, each supporting dual Xeon Scalable Series CPUs, 8x 3.5" Hot Swap HD/SSD bays (6+2 Rear) (2x Rear 3.5" bays as NVMe) and up to 1.5TB DDR4 RAM per node. Solution offers fully independent Supermicro SIOM LAN adapter options per node (multiple choices available). Each node can be online configured independently from each other with all multifaceted options available, with no restrictions, using the Multinode System Node configurator engines. System Nodes are listed below.
This solution ideal for high-end enterprise, high performance computing (HPC) clusters, Data centres and cloud computing environments.
Chassis Model 4U CSE-F424AS2-R1K23BP (F629P3-RTBN)
Description 8x 3.5" Hot Swap HD/SSD Bays per node (6x Front+2x Rear). Solution with 4x 1200W (1+1) 80plus (Titanium) 96% High-Efficiency PSUs. Power Rating Per Node 1200W.
Height 4U, 177mm Depth 737mm
Width 448mm
Chassis Colour
External Optical Drive
Telescopic Rail Kit included
Maintenance inc. all Nodes

Overall System Price
£5,187 ex VAT

System Quantity:

System Node Pricing
£559 ex VAT

Multinode System Nodes

Qty x

3 x Unconfigured Nodes Or use the Quantity Multiplier above

Node Configurator

Model F629P3-RTBN
System Node Spec 1
System Node
Node General Info Supports dual Xeon Scalable Bronze/Silver/Gold/Platinum series CPUs, 8x 3.5" Hot Swap HD/SSDs (per node) (2x 3.5" bays as NVMe). Each node comes with 1x SIOM LAN adapter by default (All LAN types are selectable for full network flexibility per node).
Node Chassis F629P3-RTBN Node Module Motherboard Quad Node Dual Xeon Scalable series (X11DPFR-SN)
Chipset Intel C621 Expansion Slots & I/O 1x PCI-e (3.0) x16 (LP), 1x PCI-e (3.0) x16 (for default SIOM LAN), 1x M.2 Socket, 2x USB 3.0 Rear, 1x TPM Header
CPU Socket Type LGA-3647 Maximum CPU 2
Maximum Ram 1536GB (12 x 128GB) Ram Slot Type DDR4 (Use in pairs, triples, quads, sixes, Linked to processor)
On-Board LAN
On-board RAID
14 port SATA (6Gb/s)(RAID 0,1,5,10)
2 port NVMe (8Gb/s)(RAID N/A - JBOD Mode only)
Onboard Management Per Node: Integrated IPMI 2.0 with Dedicated LAN (ASpeed AST2500 BMC). Supports virtual media over LAN and KVM over LAN. On-board Graphics ASpeed AST2500/64(1Head)(64MB RAM)
HD Bays
2 x 3.5"/2.5" NVMe Hot Swap
6 x 3.5" Hot Swap
Drive Support SATA (6Gb/s) / SAS2 (6Gb/s) / NVMe (8Gb/s) - 8 Ports

  24GB RAM (Total), 24GB for CPU1
On-Board Raid 14 port SATA (6Gb/s)(RAID 0,1,5,10), 2 port NVMe (8Gb/s)(RAID N/A - JBOD Mode only)
H'Swap HD/SSD2
H'Swap HD/SSD3
M.2 SSD 2
SAS/Add-in Card
On-Board Graphics ASpeed AST2500/64(1Head)(64MB RAM)
Graphics/GPU 2
LAN Installed
LAN Controller
LAN Controller 2
System Option
System Option 2
System Option 3
OS Version
Operating System
Software 2
Software 3
